Dental Light Polymerization Chamber

UV Light Polymerizer Chamber

It is a bench-top, box-type light polymerization chamber designed for dental laboratory and clinical use. It delivers controlled visible-light energy within the 400–500 nm spectrum to initiate and complete photoactivation of photopolymerizable resins.

The unit converts light-cure custom tray resin from a pliable, workable state into a rigid, dimensionally stable tray with consistent and reproducible results.

A programmable timer from 6 seconds to 99 minutes allows clinician-controlled curing cycles, minimizing operator variability. The built-in amber filter shield protects surrounding materials and personnel from stray light exposure during operation.

Designed for complete denture fabrication workflows, it supports both custom tray and surgical guide polymerization applications.

Clinical Applications

• Custom tray fabrication for complete denture
• Surgical guide polymerization
• General photopolymerizable resin curing

Technical Specification

Electrical

• Input Voltage: AC 110V / 230V
• Frequency: 50Hz / 60Hz
• Power Consumption: ≤ 30W
• Fuse Rating: 250V 1A | 125V 2A

Light Source

• Lamp Power: 27W
• Emission Wavelength: 400–500nm (visible blue light)
• Lamp Service Life: ≥ 5,000 hours

Timer & Control

• Timer Range: 0.1 min (6 sec) – 99 min
• Timer Increment: 0.1 min

Physical

• Unit Dimensions: 260 × 135 × 88 mm
• Weight: 2.1 kg
• Enclosure Material: Steel
